The Ultimate Guide to GPU Computers
The Ultimate Guide to GPU Computers

Article from | Cincoze

This article was originally published on Circuitcellar.com.

The GPU has been part of computing ever since the first pixel hit a display. Still, its role has changed dramatically from its original function to embedded GPUs, lifelike 3D gaming, and now general-purpose GPU computing.

This article takes a deep dive into this critical hardware component that powers AI, computer vision, and a whole slew of futuristic computer goodness. We will attempt to sum up what the GPU is, why it’s important, how they apply to industrial computers, what it’s used for, why you might need one, and the options available when picking them.



Definition: What is a GPU?

The graphics processing unit (GPU) is the hardware component that takes instructions for visual display and puts the pixels on the screen where they are meant to go.

According to Intel®, GPUs are designed for parallel processing and are, “used in a wide range of applications, including graphics and video rendering. Although they’re best known for their capabilities in gaming, GPUs are becoming more popular for use in creative production and artificial intelligence (AI).” (Source: Intel®)

That last part is important because the modern general-purpose GPU is no longer limited to just displaying images on the screen. It has become the powerhouse behind the processing of complex machine inputs that are possible but just too slow for the CPU. So how did this come about?



Brief history of GPU computing

For the sake of accuracy, all computers have a GPU if they display images on a screen. There are two main types. Basic GPUs, often integrated into modern CPUs, provide core functionality for most office or home situations. Dedicated graphics cards with powerful GPUs are what we refer to in this article.

NVIDIA® coined the term GPU back in 1999, with the release of the GeForce 256, touted as “world's first GPU.” (Source: ResponseSource) Although initially intended for graphics-intensive tasks, the general-purpose GPU has made its way into other fields. These include oil exploration, image processing, statistics, stock options pricing, linear algebra, and anything that needs massive-scale mathematical number-crunching.

Consequently, GPUs branched out from image rendering for games into multiple new areas. But after years of pushing CPUs to perform ever faster, why did the GPU come to take the spotlight?



What does the GPU do?

The GPU is the maths whizz in the class. It performs mathematical calculations and executes mathematical algorithms quickly.

Unlike CPUs that perform a variety of general computer tasks like access memory and hard drives, amongst others, GPUs perform a much more limited set of functions.

Parallelism is the driving force behind these capabilities. Instead of performing complex functions sequentially on a CPU with up to 18 cores, mathematical tasks are passed off to the GPU with hundreds or even thousands of cores working at the same time.

This processing power is what AI, machine vision, and deep learning require. GPU computing can be used in graphics rendering for artists and gamers, HPC and supercomputer workstations, edge and industrial fields. (Source: NVIDIA®)



The GPU’s role in visual processing

The GPU has played a vital role in creating visually stunning imaginary 3D worlds in computer games. That same core processing power now brings computers into the real world and makes them “see” in a way that allows them to make decisions on that visual input.



During the Covid-19 outbreak, by deploying automated thermal imaging systems powered by Cincoze GM-1000, it successfully performed mask detection, face recognition, image search, and footprint tracking through machine vision, helping streamline the process and lowering labor costs.

This ability to process the incoming visual data is the primary role of the GPU and is what sets a GPU computer apart from a regular one. Of course, any computer with a camera can do this in a limited capacity. Still, it’s the equivalent of a near-sighted driver trying to drive through the mist with fogged up windows after they forget their glasses at home. That’s pretty slow going if you want to arrive alive. The GPU provides the keen eyes and reaction time of an F1 driver on race day, taking in every input with intense detail, and acting on that input.

Acting on that input is key to making the “seeing” work well. So how does this play out for industrial applications?



What is an industrial GPU computer?

An industrial GPU computer incorporates the same design principles as a general industrial computer intended for harsh industrial environments. These general features could include rugged design, redundant components, shock resistance, vibration resistance, fanless design, wide operating temperature range, ESD protection, water resistance, and dust resistance.

The core differentiator is that an industrial GPU computer supports at least one GPU expansion card, typically through a PCIe x16 expansion card slot in a regular-sized computer or the smaller Mobile PCI Express Module (MXM) in an industrial embedded system.

The GPU introduces extra stress to the overall system that must be tackled. GPUs produce heat that must be dealt with through specialized cooling mechanisms that go beyond just adding fans to the system. GPUs also introduce extra power drain (the reason for all that extra heat), so the power supply to the system must be able to provide the additional power for the GPU.

The GPU, whether full-size or compact, needs adequate internal space. Intended applications are often critical systems that must operate continuously, so it becomes double important that systems stay online, and in the worst case, anticipate possible breakdowns and take evasive action to avoid damage.

Some features to look for on an industrial GPU computer include:

Cable- and jumper-free by utilizing alternative or more reliable connections. Removing cables and jumpers that can shake free removes a possible source of failure that is particular to applications where the computer experiences lots of vibration and knocks.

Extruded aluminum chassis that can wick away heat from the internal parts and into the surroundings.

Vibration and shock resistance to withstand the rigors of industrial applications. A slew of factors impact this, including the mechanical structure, rubber gasket choice and design, as well as cable- and jumper-free design. A 5/50 Grms rating is a good start, but military ratings have become the go-to choice, with MIL-STD-810G providing stringent guidelines for rugged computers.

Fanless design. Typical high-performance industrial GPU computers generate a lot of heat, so fans are needed to cool the system down. New, low-power GPUs optimize performance so that a good thermal design can wick away heat without needing fans, thereby eliminating the biggest source of mechanical failure in most computer systems.

Wide operating temperature from -40 to 70℃. This is typically enough because even for applications in industry, the application locations are designed to maintain temperatures within this range, and often a narrower range.

Cincoze GP-3000 itself is passive cooling (fanless). To deal with the thermal challenges, the GP-3000's unique omnidirectional cooling design and dust-proof external smart fan kits on both sides of the chassis effectively dissipate heat under full workloads in extreme conditions.



ESD, overcurrent, and overvoltage protection provide assurance against damage to the system from errant electrical anomalies that could occur in industrial environments. In the rare situation that system shutdown does occur, a 0.2-second reboot time reduces downtime to an absolute minimum. Wide range 9-48 VDC support allows some room for voltage fluctuations.

Easy maintenance makes it possible for onsite personnel to fix any problems. Because the last thing you want is to waste time waiting for a specialized outside technician while essential machinery sits idle. A user-friendly maintenance interface includes easy access to often hidden items, like AT/ATX power setting, clear CMOS, SIM card access, and hot-swap 2.5” SATA bay. Finally, customizing the base model, by adding PoE, LAN, and other I/O or functions, is simple through modular design, like CMI modules and CFM modules, which make these add-ons as easy as plug-and-play, and allow easy expansion at any time.

Industry certification simplifies hardware choice by setting the bar. Important certifications to consider are EN 50155 for railway applications, E-mark for in-vehicle, or even MIL-STD-810G promulgated by the US Department of Defense to qualify military equipment in the pursuit of ever-higher standards. When multiple certifications are available and widely used for particular applications, then the product should ideally have these certifications.

Before diving into the specific applications of industrial GPU computers, let’s have a quick look at what options are available.



Blurring lines: servers, rugged, and embedded GPU computers

The lines between computer categories are blurring. In the consumer realm, there were once just desktop computers and laptops, one was portable, one was not. Now it’s hard to tell where one category stops and the next begins, tablets with detachable keyboards vs. notebooks that fold over to function like tablets are more similar than different.

A similar scenario plays out in the world of industrial GPU computing. Here, we’ll divide that up into three broad categories.

AI training GPU computers are installed in a server room where temperatures are kept within very tight limits for maximum performance. As these systems are designed to train the models used by the GPU computers out in the field, they are quite a different category to the two below.

Rugged industrial GPU computers are standard computer size, but with added ruggedness expected of industrial computers. They are intended for use in the field where server room conditions are not available. They remain generally large but much pared down from their server room counterparts. They’ll also support fewer GPU expansion cards due to space limitations but do offer flexible expansion, often up to two slots. An example is Cincoze’s GP-3000 industrial GPU computer

Powerful GPU computing drives the applications requiring intensive processing parallelism. Cincoze GP-3000 is powered by Intel® workstation-grade Xeon® processor and provides powerful GPU performance supporting up to two 250 W high-end full-length (≤328 mm) graphics cards and with a total system power budget of 720 W. Check out GP-3000 video here.



Embedded industrial GPU computers are designed for small spaces. The overall footprint is smaller, they are often fanless, and the overall processing power less than the two options above. Typically the GPU options will only include mobile options like MXM. One example of a rugged MXM system is the GM-1000 embedded GPU computer.

The most overlap comes between industrial PCs and embedded systems because industrial computers can be quite small, but embedded systems are needed for the smallest systems. You can see the full range of Cincoze industrial GPU computers online.

So the general expectations and requirements are set. Now, what are the applications for industrial GPU computers?



What tasks can industrial GPU computers perform?

The broad answer is that an industrial GPU computer can perform any application that relies on human eyes and observation. However, these eyes are super-fast, super-accurate, and don’t get tired from a long day’s work. Here are some typical applications.

The rugged GPU computing platforms can accelerate the digital transformation and are becoming a potentially valuable investment in multiple verticals, including machine vision, edge computing, traffic vision, intelligent control, deep learning, and any applications requiring intensive processing parallelism and performance-driven analytics.



Machine vision

Machine vision gives “vision” to the machine, a camera looks at something (often production line items) and makes a determination of some sort. Applications include automated optical inspection, automatic sorting, and vision-guided robotic arms. Due to space limitations, a smaller embedded system is recommended.



In-vehicle

In-vehicle applications again perform tasks of “looking” at the environment. Applications include autonomous driving, driver fatigue detection, blind-spot detection, and automatic rail/road inspection. Vehicles offer a bit more flexibility with installation, with larger vehicles providing adequate space for a larger computer.



Video Surveillance

Video surveillance processes the images from CCTV systems and analyzes them for certain traits and behaviors set by the operator. Applications include on-site monitoring, behavioral prediction, and facial recognition.



Transportation

Transportation applications are aimed at controlling and predicting the movement of traffic and people within the transportation system. Applications include traffic monitoring, license-plate recognition, baggage screening, and railway/road surveillance.



Cincoze support and services

Cincoze has its finger on the pulse of GPU computing technology. Our range of GPU computers offers high reliability, and application-driven designs that will make you wonder why you didn’t switch earlier. We achieve these great results through effective manufacturing, and stringent tests ensure the consistent high quality of our products.

We design all of our GPU computers with expandability and upgradability in mind. Both MXM and PCIe expansion modules allow GPU computing power tailored to the application’s needs, providing a balance of cost to performance and allowing room for future upgrades. Oh, and we’ve validated NVIDA and AMD GPUs to ensure compatibility out-the-box.

Cincoze’s GPU computers provide powerful computing performance and support various form factors of GPU expansion cards such as MXM and Full-length PCIe GPU card. Built with a high power budget with optimized thermal design, these GPU computers can operate under 100% loading of CPU and GPU stably.



And speaking of future upgrades, they are only possible due to Cincoze’s focus on GPU computers’ longevity with various features extending the working life as far as feasibly possible.

The icing on the cake is our world-class service and support that won’t leave you hanging or waiting for a response. We know our service is good because our customers keep coming back. So feel free to drop our tech wizards with any questions you might have.
